HCT402-2J Dual-Joystick Wireless Hydraulic Control Remote is the handheld unit from AXI Technology's HCT402 hydraulic-lever conversion kit with two independent proportional joysticks — no servo motor, mounting bracket or wiring harness included. Drive 2 hydraulic levers independently from one remote; use each joystick's left/right axis as well and control up to 4 HCT402 servo motors proportionally from a single hand.
Housing, radio link and protection class are the same as the standard HCT402 remote: IP67 body, AXI's proprietary XRF-encrypted wireless link, USB charging. If you already run an HCT402 system, adding a remote for the second (and third, fourth) lever never touches the motor side — you pair the new remote to your existing HC402 servo motors yourself, within 50 metres.
At a Glance
Highlight Features
How to Pair It
Technical Specifications
| Model | HCT402-2J (dual joystick) |
| Product Type | Remote only (no servo motor, bracket or wiring) |
| Controls | 2 × 2-axis proportional joystick + Emergency Stop |
| Motors Driven | 2 independent HC402 servo motors; up to 4 using the joysticks' left/right axes |
| Link | XRF encrypted (AXI proprietary) |
| Protection Class | IP67 |
| Operating Temperature | −20 °C / +85 °C |
| Charging | USB via AXI-Link 3-pin connector — 3h to 80%, 6h to full |
| Battery Life | 4–16 days (usage-dependent) |
| Pairing | Per motor, user-performed, within 50 m |
| Compatibility | Standard HCT402 (HC402 servo motor) — see compatibility warning |
| Warranty | 24 months full coverage |
| Made In | 100% AXI Technology R&D — Türkiye |
When to Choose This
| Situation | Benefit |
|---|---|
| Two hydraulic levers | Crane boom + hook, tipper + tailgate, farm-machine lift + tilt — two levers driven independently from one hand. |
| 3–4 hydraulic levers | Assign the joysticks' left/right axes as well for proportional wireless control of up to four levers. |
| Adding motors to an existing HCT402 | Grow the system by swapping only the remote and pairing the new motors — the motor side stays untouched. |
| Spare / second operator | A replacement for lost or damaged dual-joystick remotes, or an extra unit for a second operator. |
What's in the Box
This remote is only compatible with standard HCT402 systems (HC402 servo motor); every lever you drive needs its own HC402 servo motor. The HCT402-D differential-drive kit uses a wired joystick, and the HCT402-KM remote adds 2 extra buttons (Starter and Stop) — both are physically different remotes and are not compatible. For a single lever see the single-joystick HCT402 replacement remote. If you're unsure, send a photo of your current remote and we'll confirm the right product.
HCT402-2J Dual-Joystick Wireless Hydraulic Control Remote — a handheld unit that drives 2 HCT402 servo motors on two independent proportional joysticks, or up to 4 using the left/right axes. Add it to your existing HCT402 system without touching the motor side, pairing it yourself.
