Name: HCT402 Replacement Remote Control Only - IP67
Brand: AXI Teknoloji
SKU: AXI-HCT402-RC
Price: 7827.76 TRY
Availability: InStock

The handheld remote only from the HCT402 hydraulic-lever kit — for lost, damaged or spare units. Joystick + Emergency Stop, IP67, self-pair within 50 m.

HCT402 Replacement Remote Control is the handheld unit only from AXI Technology's HCT402 hydraulic-lever conversion kit — no servo motor, mounting bracket or wiring harness included. If you already have a working HCT402 system installed, this lets you buy just the remote.

The remote is identical hardware to the one that ships with a standard HCT402 kit: get it to replace a lost or damaged remote, hand a second operator their own unit, or keep spare stock for fleet vehicles running HCT402. You pair it to your existing HC402 servo motor yourself, within 50 metres.

Swap without touching the install. If the remote is lost or faulty, the servo motor, bracket and wiring on your vehicle stay untouched — just pair the new remote and keep working.

At a Glance

Controls

2-axis proportional joystick + Emergency Stop

Link

XRF encrypted (AXI proprietary)

Protection

IP67

Charging

USB, AXI-Link 3-pin connector · 3h → 80%

Pairing Range

Within 50 m

Warranty

24 months full coverage

Highlight Features

Identical to the original

Same hardware as the standard HCT402 remote — no reinstall or recalibration, just pair the remote.

Self-pairing

No service visit needed — pair it to the motor yourself within 50 m using the joystick + Emergency Stop method.

IP67 rated

Dust and water resistant housing, built for field use.

USB charging

Charges from any standard USB source (car charger, power bank, adapter) — charging cable included.

Same precision

Millimetre precision near center, fast response at the extremes — HCT402's joystick feel carries over exactly.

Emergency Stop included

The red Emergency Stop on the remote can halt lever motion safely at any time.

How to Pair It

Prep the vehicle and motor

Power the HC402 servo motor and keep the lever's range of motion clear.

Joystick right + release Emergency Stop

On the new remote, hold the joystick right while releasing the Emergency Stop button to start pairing.

Test it

Move the lever slowly in both directions to confirm response, then test the Emergency Stop.

Technical Specifications

Product Type	Remote only (no servo motor, bracket or wiring)
Controls	2-axis proportional joystick + Emergency Stop
Link	XRF encrypted (AXI proprietary)
Protection Class	IP67
Operating Temperature	−20 °C / +85 °C
Charging	USB via AXI-Link 3-pin connector — 3h to 80%, 6h to full
Battery Life	4–16 days (usage-dependent)
Pairing	Joystick-right + Emergency-Stop-release method, user-performed, within 50 m
Compatibility	Standard HCT402 (HC402 servo motor) — see compatibility warning
Warranty	24 months full coverage
Made In	100% AXI Technology R&D — Türkiye

When to Choose This

Situation	Benefit
Lost / damaged remote	Servo motor and mounting stay in place — only the remote is replaced and paired.
Second operator	When more than one person runs the system, each gets their own remote.
Business continuity	Keep a spare on hand so a failure in the field doesn't stop work.
Fleet use	Order spares individually for businesses running HCT402 across multiple vehicles.

What's in the Box

1 × HCT402 wireless remote (joystick + Emergency Stop)

1 × USB charging cable

Quick pairing instructions

Compatibility warning

This remote is only compatible with standard HCT402 systems (HC402 servo motor). The HCT402-D differential-drive kit uses a wired joystick, and the HCT402-KM remote adds 2 extra buttons (Starter and Stop) — both are physically different remotes and are not compatible with this unit. If you're unsure, send a photo of your current remote and we'll confirm the right product.

HCT402 Replacement Remote Control — the handheld unit only, for existing HCT402 hydraulic-lever systems. Pair it yourself, without touching the servo motor install, when you lose a remote, need a spare, or add a second operator.
