ST200 Wireless Crane Remote Control Set - 6 Channel

ST200 Wireless Crane Remote Control Set - 6 Channel

Rechargeable IP67 transmitter + IP67 outdoor 6-channel receiver. 150m range.

ST200 — 6 Channel (IP67 Outdoor Type) is a premium control set composed of a rechargeable IP67 transmitter and a fully IP67 outdoor receiver, allowing you to control three motors simultaneously or six separate functions in outdoor conditions. It is ideal for port cranes, farm automation, triple-axis platforms and panel-less field installations.

Thanks to the dual-side IP67 sealing of the transmitter and receiver, ~150 m range and 6 independent channels, it delivers an uninterrupted, premium-grade control experience in environments with heavy rain, mud, dust and humidity.

› Six channels, outdoor, panel-less installation. On sites where you'll manage three motors at once, eliminate the need to run a panel; connect the IP67 receiver directly next to the machine.

ST200 — 6 Channel at a Glance

⚡ Transmitter
Li-Po rechargeable · IP67
◆ Range
~150 m open field
⚙ Receiver
IP67 outdoor · sealed
○ Supply
12/24V DC · 220V AC
⇄ Channels
6 independent channels
○ Durability
Impact · water · dust · humidity
★ Segment
Premium field

Key Features

✓ 6 independent channels
Three motors forward–reverse or six separate functions; multi-axis control with a single transmitter.
✓ Dual-side IP67
Both transmitter and receiver fully sealed — class-leading durability against field conditions.
✓ Rechargeable professional transmitter
No battery swaps required; charge at end of shift, use the next day.
✓ Long range
~150 m safe open-field communication, fits large construction sites and port applications.
✓ Sealed cable entry
Cable-gland mounting preserves IP67 protection for years.
✓ Panel-less field installation
Connect the receiver directly next to the machine — minimal cable runs, easy maintenance.

Typical 6-Channel Scenarios

ScenarioChannel mapping
◆ Port craneCH1–CH2: Hoist motor · CH3–CH4: Boom motor · CH5–CH6: Slew motor
◆ Twin-motor farm gateCH1–CH2: Left wing · CH3–CH4: Right wing · CH5–CH6: Lock/lighting
◆ Triple-axis platformCH1–CH2: Up/down · CH3–CH4: Forward/reverse · CH5–CH6: Slew left/right
◆ Field automationCH1–CH2: Pump A · CH3–CH4: Pump B · CH5–CH6: Pump C

How Does It Work?

1
Place the receiver in the field
Mount the IP67 receiver next to the machine or at a suitable outdoor point.
2
6-channel wiring
Wire each relay output to the corresponding motor/valve lines and route cables through the glands.
3
Charge the transmitter
Full charge before first use; pair via the learning procedure.
4
Take it to the field
Uninterrupted multi-channel control outdoors in any weather.

Technical Specifications

ModelST200 (6 channels)
TransmitterRechargeable Li-Po · IP67 · ~150 m range
ReceiverIP67 outdoor · sealed body · 6×5A relay output (COM/NO, no NC)
Supply12/24V DC or 220V AC
Control type6 channels — three motors forward/reverse or multi-direction
Protection classTransmitter IP67 · Receiver IP67
ApplicationOutdoor multi-motor and multi-function machines

Use Cases

SectorBenefit
◆ Port & coastal cranesSalt-air durability, three motors on a single transmitter.
◆ Twin-leaf garden gatesIndependent control of each leaf plus lock/lighting, panel-less mounting.
◆ Agricultural field automationManage pumps, valves and motors from a single transmitter.
◆ Multi-axis construction machinesTrouble-free operation in dusty, muddy outdoor conditions.

Relay Output: AC/DC Motor and Contactor Wiring

Each channel of the receiver is a 5A relay with COM and NO terminals (no NC). Since these are dry contact relays, they can drive both DC loads and 220V/380V AC motors — even powerful star-delta AC motors can be driven with a suitable contactor and panel setup.

Relay output6 × 5A (COM · NO (no NC))
Direct AC motor connectionUp to 350W
Above 350W / for longer lifeA contactor is recommended
DC motor speed/ramp controlThe relay output can trigger the manual control input of AXI DC motor drivers (ST42 / KS250 / PT500) for current-protected, ramped and speed-adjustable control
› Want speed-adjustable, current-protected DC motor control? Instead of wiring the relay output directly to the motor, connect it to the manual control input of AXI's ST42 / KS250 / PT500 DC motor drivers — you gain current limiting, soft start/stop ramping and speed control. Wiring diagrams are being prepared and will be added to this page's technical documents section once available.

What's in the Box

✓ IP67 rechargeable transmitter (6 channels)
✓ IP67 outdoor receiver (6 channels)
✓ AXI-Link charging adapter and cable
✓ Antenna and cable glands
✓ Wiring diagram
✓ User manual

Demo Videos

ST200 — 6 Channel — AXI Teknoloji's premium IP67 transmitter + outdoor receiver, the ideal control set for multi-motor field projects.
