GS740 is a next-generation conversion kit that converts the engine speed of diesel and petrol engines into electronic control via a cable-pull servo motor system — without removing the mechanical throttle lever.
The precision potentiometer in the set adjusts engine speed steplessly; the working speed is saved to memory by holding the IP67 metal button for 3 seconds. A single press toggles instantly between idle and the saved working speed.
› One-press speed memory. Stop re-adjusting the throttle at every headland — eliminate engine wear and fuel waste.
GS740 at a Glance
⚡ Voltage
12V – 24V DC
◆ Protection
IP67 metal button
⚙ Mounting
Non-invasive top mount
⇄ Memory
One press: idle ↔ working
○ Maintenance
No lubrication required
★ Warranty
36 Months
Key Features
✓ Non-invasive mounting
The mechanical throttle lever stays in place. The cable-pull servo motor is connected from above without altering the original structure.
✓ Memorized speed control
Hold the IP67 metal button for 3 s to save the working speed. Toggle between idle and working speed with a single press.
✓ Precision potentiometer
Stepless speed adjustment. Set the desired rpm with fingertip precision.
✓ 12V & 24V compatible
A single kit, a wide vehicle range. Installs on light- and heavy-duty vehicles alike.
✓ Friction-reducing cable
Special plastic liner inside the cable — needs no extra lubrication, maintenance load drops to zero.
✓ 36-month warranty
Long-term, uninterrupted use backed by AXI Teknoloji's engineering warranty.
How Does It Work?
1
Mount it
Position the servo motor on top of the throttle lever and attach the cable.
2
Set the speed
Choose the working speed steplessly with the potentiometer.
3
Save to memory
Hold the IP67 button for 3 seconds; the speed is saved.
4
Toggle with one press
A short press instantly toggles between idle and working speed.
Optional Upgrades
| Module | Function |
|---|---|
| › Wireless remote | Remote speed control from the tractor cabin or out in the field. |
| › Active feedback rpm hold | A sensor reads engine rpm and automatically holds the speed steady when the engine is loaded. |
| › Lift / auto-steering integration | Automatic transition to idle on a trigger signal — no manual intervention needed in turns. |
Technical Specifications
| Model | GS740 |
| Compatible engine type | Diesel / Petrol (mechanical throttle lever) |
| Operating voltage | 12V – 24V DC |
| Actuator type | Cable-pull servo motor |
| Speed adjustment | Precision potentiometer — stepless |
| Memory button | IP67 metal — hold for 3 s |
| Cable structure | Special friction-reducing plastic inner liner |
| Maintenance | No lubrication required |
| Warranty | 36 Months |
Use Cases
| Sector | Benefit |
|---|---|
| ◆ Tractors | Constant rpm in field work, one-press comfort at the headlands. |
| ◆ Water motors | Precise operation at the desired rpm in irrigation pumps. |
| ◆ Generators | Stable rpm under load changes, frequency stability. |
| ◆ Construction equipment | Efficiency and fuel savings in constant-speed operations. |
What's in the Box
✓ Cable-pull servo motor
✓ Precision potentiometer
✓ IP67 metal button
✓ Cable set
✓ Mounting hardware
✓ User manual
Demo Videos
GS740 — AXI Teknoloji's electronic throttle/speed control solution for diesel and petrol engines.
